Mining & Quarrying Series

HD 100 — Down-the-Hole Drill

Drill Diameter4” to 16

Depth30 m

HD 100 — Down-the-Hole Drill

Compact, versatile DTH rig for 4″–16″ wells up to 200 m

A compact, hydraulic DTH rig for dependable water-well and utility drilling up to 200 meters. HD 100 balances penetration speed and control across mixed formations, pairing a wide hole-size range (4″–16″) with flexible compressor options for clean, efficient air drilling on varied sites.

Product Specifications

Download HD 100 specification sheet (PDF)

Why KLR universal

32 years of expertise
Industry leader
Trusted in 60 countries
Excellent after-sales support

Contact & Support

Parameter	Value
Compressor capacity	3.5″ (89 mm) to 5″ (127mm)
Single pass (Standard)	3 m
Multi pass capacity	30m
Horizontal Drilling	20m
Rotation Torque	2100 Nm
Rotation Speed	80 RPM
Pull down Mechanism	motor with Chain
Feed force	3300 lbs
Hoist force	3300 lbs
Compressor capacity	450 cfm@150 / 200 psi
