Piling & Foundation Rigs

CP20 — Rotary & Auger Drill

Drill DiameterUp to 24″

DepthUp to 50 m

CP20 — Rotary & Auger Drill

Deck-engine rotary/auger rig for fast, clean boreholes

CMP 40 combines a powerful deck engine with high-torque rotary drive and on-board mud handling, delivering efficient foundations and utility bores in soft, hard, unconsolidated, and alluvial formations.

Product Specifications

Download CMP 40 specification sheet (PDF)

Why KLR universal

32 years of expertise
Industry leader
Trusted in 60 countries
Excellent after-sales support

Contact & Support

Parameter	Value
Hole diameter (rotary) Hole diameter (auger)	300–1200 mm Up to 24″ (610 mm)
Max depth	50 m
Carrier	New Holland / as per customer request
Prime mover & Power	Deck engine, 105 HP
Formations	Soft/hard/unconsolidated/alluvial
Mast	Max pull-up force 5,500 kgf Max pull-down force 2,500 kgf Feed / pull-up speed – 35 m/min
Rotary head (standard) Rotary head (optional)	Max speed 0–200 rpm • Max torque 250 kg·m Max speed 0–160 rpm • Max torque 320 kg·m
Rod handling capacity	Rotary drilling 3 m • Auger drilling 6 m
Rod changer	Manually operated single rod changer
Mud pump	On-board 1000 LPM pump (up to 16″ drilling); external mud pump for >16″
