TP30 — Rotary & Auger Drill
Drill Diameter
Up to 24″
Depth
Up to 50 m
Tractor-mounted rotary/auger rig for fast, clean boreholes
PD 1200 combines a robust mast with high-torque rotary drive and on-board mud handling for efficient foundation, utilities, and civil works across soft, hard, unconsolidated, and alluvial formations.
Product Specifications
Why KLR Universal
- 40+ years of expertise
- Industry leader
- Trusted in 60 countries
- Excellent after-sales support
| Parameter | Value |
|---|---|
| Hole diameter (rotary)Hole diameter (auger) | 300–1200 mm Up to 24″ (610 mm) |
| Max depth | 50 m |
| Carrier | New Holland / as per customer request |
| Prime mover & Power | Tractor engine, 75 HP |
| Formations | Soft/hard/unconsolidated/alluvial |
| Mast | Max pull-up force 4,500 kgf Max pull-down force 2,400 kgf Feed / pull-up speed – 35 m/min |
| Rotary head (standard)Rotary head (optional) | Max speed 0–200 rpm • Max torque 250 kg·m Max speed 0–160 rpm • Max torque 320 kg·m |
| Rod handling capacity | Rotary drilling 3 m • Auger drilling 6 m |
| Rod changer | Manually operated single rod changer |
| Mud pump | On-board 1000 LPM pump (up to 16″ drilling); external mud pump for >16″ |
